Characteristics:

• Combustion chamber in thick steel

• Fire door and brazier in cast iron

• Shell and tube heat exchanger (manual cleaning)

• Watertight tank

• Removable ash drawer

• Front ambient ventilation with dedicated motor, which can be excluded

• Ceramic glow plug for rapid ignition

• Circulator with PWM control

• Thermal and water pressure safety devices

• 3 bar safety valve

• Expansion tank

• Air vent

• Pressure transducer with visualization on display

• Possibility of exit for fume discharge: rear

• Innovative adaptive system for regulation and constant maintenance of the combustion air over time

• IR Touch remote control

• BlackLCD

Dimensions (LxHxP): 633x1176x626 mm

Net Weight: 214 Kg

Efficiency: 92.8 - 93.8%

Hourly consumption: 1.2 - 4.8 kg/h

Flue outlet diameter (Ø: )100 mm P

Total tank capacity: 35 kg

Energy class: A+

DM186 Environmental Certification: 4 STARS
