Characteristics:

• New «5 star» brazier

• Combustion chamber in high thickness steel

• Cast iron fire door and brazier

• Watertight tank

• Removable ash drawer

• Excludable front ventilation

• Ceramic spark plug for quick ignition

• Circulator with PWM control

• FPC – Innovative adaptive system for regulating and maintaining the combustion air constant over time

• PRO AIR SETUP. Choice between: Quiet/Regular/Boost

• Home automation integration with “Alexa” (Amazon). NB Only in combination with the “Grey label” WiFi module – optional – and use of the TotalControl 3.0 App. “Alexa” (Amazon) service and peripheral not included.

• Anti-condensation management

• Easy Setup

• Easy Control

• Self-Control

• IR Touch Remote Control

• Black LCD

5.1-17.5 kW Nominal thermal power

13.0 kW-H 2 O Power output to water

502 m 3 m³ heatable

Dimensions (LxHxD): 550x1149x601 mm

Hourly consumption: 1.1 –3.8 kg/h

Total tank capacity: ~ 24 kg

Smoke outlet diameter (Ø): 80 mm post

Yield: 94.2 - 92.4 %

Net Weight: 190 kg

Environmental Certification DM186: 5 STARS

Energy Class: A+
