Characteristics:

• Front room ventilation with dedicated motor, excludable

• Brushless pellet loading motor.

• Circulator with PWM control

• Ceramic spark plug for quick ignition

• Self-cleaning brazier with brushless motor

• Air vent

• Possibility of exit for smoke exhaust: rear

• Wide view of the flame

• Pressure transducer with display

• Combustion chamber in high thickness steel

• Handle with ergonomic grip

• Cast iron fire door and brazier

• Probe in combustion chamber

• Shell and tube heat exchanger (manual cleaning)

• Thermal and water pressure safety devices

• Expansion vessel

• 3 bar safety valve

• Removable ash drawer

• IR Touch Remote Control

• Black LCD

4.6-16.2kW

Nominal thermal power

14.0 kW-H2O

Power output to water

465 m3

m³ heatable

Dimensions (LHP) 576 x 1157 x 621 mm

Net Weight 210 kg

Yield 90.6 - 90.9 %

Hourly consumption 3.7 kg/h

Smoke exhaust diameter 100 mm P

Total tank capacity 30 kg

Energy Class A+

Environmental Certification DM186 4 STARS
