Characteristics:

• High thickness steel combustion chamber

• Cast iron fire holder and brazier

• Shell and tube heat exchanger with automatic cleaning

• Removable ash compartment

• Front room ventilation with dedicated motor and comfort function, which can be excluded

• Ceramic glow plug for quick ignition

• Circulator with PWM control

• Pellet level sensor

• Emergency module

• Thermal and water pressure safety devices

• 3 bar safety valve

• Expansion vessel

• Air vent

• Wide view of the flame

• Possibility of exit for fume exhaust: superior

• Hydraulic connections on the upper part

• Lifting handles to facilitate handling

• Radio control

5.7-19.0 kW Nominal heat output

14.9 kW-H 2 O Power delivered to the water

545 m 3 m³ heated

Hourly consumption 1.3 - 4.3 Kg/h

Fume exhaust diameter 100 mm S

Dimensions (LHP)821x648x608 mm

Net weight 220 kg

Efficiency 91.6 - 90.4 %

Total tank capacity 18 kg

Energy Class A+

DM186 4 STAR Environmental Certification
